Order code: | PF-23 |
---|---|
|
Round cable ferrite core sleeve CORE-TECH K5ARH9.5X5.2X9.5 |
Conditions: | N (The product is brand new) |
Permeability (µi): | 700 |
Impedance (min.) @ 100 MHz: | 80 Ω |
Outer diameter: | 9.5 mm (0.374 in) |
Inner diameter: | 5.2 mm (0.205 in) |
Length: | 9.5 mm (0.374 in) |
Application: | round cable |
Order code: | PF-24 |
---|---|
|
Round cable ferrite core sleeve CORE-TECH K5ARH9.5X4.7X12.7 |
Conditions: | N (The product is brand new) |
Permeability (µi): | 700 |
Impedance (min.) @ 100 MHz: | 100 Ω |
Outer diameter: | 9.5 mm (0.374 in) |
Inner diameter: | 4.7 mm (0.185 in) |
Length: | 12.7 mm (0.5 in) |
Application: | round cable |
Order code: | SC-02 |
---|---|
|
EMI filtering ferrite core with clip for ribbon cables with adhesive base |
Conditions: | N (The product is brand new) |
Application: | ribbon cable |
Max. cable size: | 65 mm |
Order code: | SC-15 |
---|---|
|
EMI filtering ferrite core with clip for 3.5-4.5 mm round cables KE KITAGAWA LF 20.0x5.1x9.9 |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 200 Ω |
Application: | round cable |
Max. cable size: | Ø4.5 mm |
Colour: | black |
Order code: | SC-17 |
---|---|
|
EMI filtering ferrite split core for ribbon cables KE KITAGAWA SSH-40-12-F |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 61 Ω |
Application: | ribbon cable |
Max. cable size: | 34 mm |
Order code: | SC-GRFC10B |
---|---|
|
EMI filtering ferrite core with clip for 9.5-10.5 mm round cables KE KITAGAWA GRFC-10-BK |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 105 Ω |
Application: | round cable |
Max. cable size: | Ø9.5 - 10.5 mm |
Colour: | black |
Order code: | SC-GRFC10W |
---|---|
|
EMI filtering ferrite core with clip for 9.5-10.5 mm round cables KE KITAGAWA GRFC-10 |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 105 Ω |
Application: | round cable |
Max. cable size: | Ø9.5 - 10.5 mm |
Colour: | white |
Order code: | SC-GRFC13B |
---|---|
|
EMI filtering ferrite core with clip for 12.5-13.5 mm round cables KE KITAGAWA GRFC-13-BK |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 95 Ω |
Application: | round cable |
Max. cable size: | Ø12.5 - 13.5 mm |
Colour: | black |
Order code: | SC-GRFC13W |
---|---|
|
EMI filtering ferrite core with clip for 12.5-13.5 mm round cables KE KITAGAWA GRFC-13 |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 95 Ω |
Application: | round cable |
Max. cable size: | Ø12.5 - 13.5 mm |
Colour: | white |
Order code: | SC-RFC5B |
---|---|
|
EMI filtering ferrite core with clip for 4.5-5.5 mm round cables KE KITAGAWA RFC-5-BK |
Impedance (min.) @ 100 MHz: | 177 Ω |
Application: | round cable |
Max. cable size: | Ø5.5 mm |
Order code: | SC-RFC6B |
---|---|
|
EMI filtering ferrite core with clip for 5.5-6.5 mm round cables KE KITAGAWA RFC-6-BK |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 177 Ω |
Application: | round cable |
Max. cable size: | Ø6.5 mm |
Colour: | black |
Order code: | SC-RFC6W |
---|---|
|
EMI filtering ferrite core with clip for 5.5-6.5 mm round cables KE KITAGAWA RFC-6 |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 177 Ω |
Application: | round cable |
Max. cable size: | Ø6.5 mm |
Colour: | white |
Order code: | SC-RFC9B |
---|---|
|
EMI filtering ferrite core with clip for 9-10 mm round cables KE KITAGAWA RFC-9-BK |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 183 Ω |
Application: | round cable |
Max. cable size: | Ø10 mm |
Colour: | black |
Order code: | SC-RFC9W |
---|---|
|
EMI filtering ferrite core with clip for 9-10 mm round cables KE KITAGAWA RFC-9 |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 183 Ω |
Application: | round cable |
Max. cable size: | Ø10 mm |
Colour: | white |
Order code: | SC-SFC5B |
---|---|
|
EMI filtering ferrite core with clip for 5-6 mm round cables KE KITAGAWA SFC-5-BK |
Conditions: | N (The product is brand new) |
Impedance (min.) @ 100 MHz: | 242 Ω |
Application: | round cable |
Max. cable size: | Ø5 mm to Ø6 mm |
Colour: | black |
