RF and microwave laminates

Double side laminate with PTFE woven fiberglass dielectric

Order code:	AD350-60-202X228
	Double side laminate with PTFE woven fiberglass dielectric Arlon AD-350
Conditions:	N (The product is brand new)
Series:	AD-350
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	3.50
Dielectric thikness:	1.520 mm (0.060 in)
Copper cladding:	0.5 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.003 @ 10 GHz
Board size (metric):	202 x 228 mm
Board size (inch):	8 x 9 in

Go to product page AD350-60-202X228

White alumina substrate board

Order code:	ALM-02
	White alumina substrate board
Conditions:	N (The product is brand new)
Laminate type:	white alumina
Dielectric constant (εr):	9.90
Dielectric thikness:	0.630 mm (0.025 in)
Copper cladding type:	without copper
Dissipation factor (tan δ):	0.0002 @ 10 GHz
Board size (metric):	25.4 x 25.4 mm
Board size (inch):	1 x 1 in

Go to product page ALM-02

White alumina substrate board

Order code:	ALM-03
	White alumina substrate board
Conditions:	N (The product is brand new)
Laminate type:	white alumina
Dielectric constant (εr):	9.90
Dielectric thikness:	0.254 mm (0.010 in)
Copper cladding type:	without copper
Dissipation factor (tan δ):	0.0002 @ 10 GHz
Board size (metric):	25.4 x 50.8 mm
Board size (inch):	1 x 2 in

Go to product page ALM-03

White alumina substrate board

Order code:	ALM-04
	White alumina substrate board
Conditions:	N (The product is brand new)
Laminate type:	white alumina
Dielectric constant (εr):	9.90
Dielectric thikness:	0.630 mm (0.025 in)
Copper cladding type:	without copper
Dissipation factor (tan δ):	0.0002 @ 10 GHz
Board size (metric):	25.4 x 50.8 mm
Board size (inch):	1 x 2 in

Go to product page ALM-04

White alumina substrate board

Order code:	ALM-05
	White alumina substrate board
Conditions:	N (The product is brand new)
Laminate type:	white alumina
Dielectric constant (εr):	9.90
Dielectric thikness:	0.630 mm (0.025 in)
Copper cladding type:	without copper
Dissipation factor (tan δ):	0.0002 @ 10 GHz
Board size (metric):	50.8 x 50.8 mm
Board size (inch):	2 x 2 in

Go to product page ALM-05

Double side laminate with PTFE/ceramic nonwoven fiberglass ...

Order code:	AR450-0620-10S3
	Double side laminate with PTFE/ceramic nonwoven fiberglass dielectric Arlon AR450
Conditions:	N (The product is brand new)
Series:	AR450
Laminate type:	nonwoven fiberglass/PTFE ceramic
Dielectric constant (εr):	4.50
Dielectric thikness:	1.570 mm (0.062 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0035 @ 10 GHz
Capacitance per cm2:	2.5 pF
Board size (metric):	114 x 202 mm
Board size (inch):	4.5 x 8 in

Go to product page AR450-0620-10S3

Double side laminate with PTFE/ceramic nonwoven fiberglass ...

Order code:	AR450-0620-10S4
	Double side laminate with PTFE/ceramic nonwoven fiberglass dielectric Arlon AR450
Conditions:	N (The product is brand new)
Series:	AR450
Laminate type:	nonwoven fiberglass/PTFE ceramic
Dielectric constant (εr):	4.50
Dielectric thikness:	1.570 mm (0.062 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0035 @ 10 GHz
Capacitance per cm2:	2.5 pF
Board size (metric):	101 x 228 mm
Board size (inch):	4 x 9 in

Go to product page AR450-0620-10S4

Double side laminate with PTFE/ceramic nonwoven fiberglass ...

Order code:	AR450-0620-10S5
	Double side laminate with PTFE/ceramic nonwoven fiberglass dielectric Arlon AR450
Conditions:	N (The product is brand new)
Series:	AR450
Laminate type:	nonwoven fiberglass/PTFE ceramic
Dielectric constant (εr):	4.50
Dielectric thikness:	1.570 mm (0.062 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0035 @ 10 GHz
Capacitance per cm2:	2.5 pF
Board size (metric):	101 x 114 mm
Board size (inch):	4 x 4.5 in

Go to product page AR450-0620-10S5

Double side laminate with PTFE woven fiberglass dielectric

Order code:	CC217-0150-10S1
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp CuClad217 H1/H1 0150
Conditions:	N (The product is brand new)
Series:	CuClad 217
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.17
Dielectric thikness:	0.380 mm (0.015 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0009 @ 10 GHz
Capacitance per cm2:	5.05 pF
Board size (metric):	305 x 457 mm
Board size (inch):	12 x 18 in

Go to product page CC217-0150-10S1

Double side laminate with PTFE woven fiberglass dielectric

Order code:	CC217-0150-10S2
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp CuClad217 H1/H1 0150
Conditions:	N (The product is brand new)
Series:	CuClad 217
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.17
Dielectric thikness:	0.380 mm (0.015 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0009 @ 10 GHz
Capacitance per cm2:	5.05 pF
Board size (metric):	228 x 305 mm
Board size (inch):	9 x 12 in

Go to product page CC217-0150-10S2

Double side laminate with PTFE woven fiberglass dielectric

Order code:	CC217-0150-10S3
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp CuClad217 H1/H1 0150
Conditions:	N (The product is brand new)
Series:	CuClad 217
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.17
Dielectric thikness:	0.380 mm (0.015 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0009 @ 10 GHz
Capacitance per cm2:	5.05 pF
Board size (metric):	152 x 228 mm
Board size (inch):	6 x 9 in

Go to product page CC217-0150-10S3

Double side laminate with PTFE woven fiberglass dielectric

Order code:	CC217-0150-10S4
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp CuClad217 H1/H1 0150
Conditions:	N (The product is brand new)
Series:	CuClad 217
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.17
Dielectric thikness:	0.380 mm (0.015 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0009 @ 10 GHz
Capacitance per cm2:	5.05 pF
Board size (metric):	114 x 152 mm
Board size (inch):	4.5 x 6 in

Go to product page CC217-0150-10S4

Double side laminate with PTFE woven fiberglass dielectric

Order code:	DC870-0300-10S1
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp DiClad870-0300-H1-H1
Conditions:	N (The product is brand new)
Series:	DiClad 870
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.33
Dielectric thikness:	0.760 mm (0.030 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0013 @ 10 GHz
Capacitance per cm2:	2.7 pF
Board size (metric):	305 x 457 mm
Board size (inch):	12 x 18 in

Go to product page DC870-0300-10S1

Double side laminate with PTFE woven fiberglass dielectric

Order code:	DC870-0300-10S2
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp DiClad870-0300-H1-H1
Conditions:	N (The product is brand new)
Series:	DiClad 870
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.33
Dielectric thikness:	0.760 mm (0.030 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0013 @ 10 GHz
Capacitance per cm2:	2.7 pF
Board size (metric):	228 x 305 mm
Board size (inch):	9 x 12 in

Go to product page DC870-0300-10S2

Double side laminate with PTFE woven fiberglass dielectric

Order code:	DC870-0300-10S3
	Double side laminate with PTFE woven fiberglass dielectric Rogers Corp DiClad870-0300-H1-H1
Conditions:	N (The product is brand new)
Series:	DiClad 870
Laminate type:	woven fiberglass/PTFE
Dielectric constant (εr):	2.33
Dielectric thikness:	0.760 mm (0.030 in)
Copper cladding:	1 OZ
Copper cladding type:	double sided
Dissipation factor (tan δ):	0.0013 @ 10 GHz
Capacitance per cm2:	2.7 pF
Board size (metric):	152 x 228 mm
Board size (inch):	6 x 9 in

Go to product page DC870-0300-10S3
