RF coaxial cable assemblies

Cable assembly, 2x SMA male, SM141, 6.6 cm

Order code:	CID-201
	Cable assembly, 2x SMA male, SM141, 6.6 cm Huber+Suhner SM141/2X11SMA50315/66MM
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	SM141
Length:	6.6 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	18 GHz
Impedance:	50 Ohm

Go to product page CID-201

Cable assembly, 2x SMA male, HF141-50, 10 cm

Order code:	CID-202
	Cable assembly, 2x SMA male, HF141-50, 10 cm QAXIAL S02S02-23-00100
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	HF141-50
Length:	10 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	18 GHz
Impedance:	50 Ohm

Go to product page CID-202

Cable assembly, 2x SMA male, HF141-50, 15 cm

Order code:	CID-203
	Cable assembly, 2x SMA male, HF141-50, 15 cm QAXIAL S02S02-23-00150
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	HF141-50
Length:	15 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	18 GHz
Impedance:	50 Ohm

Go to product page CID-203

Cable assembly, 2x SMA male, HF141-50, 26.5 cm

Order code:	CID-204
	Cable assembly, 2x SMA male, HF141-50, 26.5 cm QAXIAL S02S02-23-00265
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	HF141-50
Length:	26.5 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	20 GHz
Impedance:	50 Ohm

Go to product page CID-204

Cable assembly, 2x SMA male, HF141-50, 20 cm

Order code:	CID-205
	Cable assembly, 2x SMA male, HF141-50, 20 cm QAXIAL S02S02-23-00200
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	HF141-50
Length:	20 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	20 GHz
Impedance:	50 Ohm

Go to product page CID-205

Cable assembly, 2x SMA male, HF141-50, 25 cm

Order code:	CID-206
	Cable assembly, 2x SMA male, HF141-50, 25 cm QAXIAL S02S02-23-00250
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	HF141-50
Length:	25 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	26.5 GHz
Impedance:	50 Ohm

Go to product page CID-206

Cable assembly, 2x SMA male, HF141-50, 30 cm

Order code:	CID-207
	Cable assembly, 2x SMA male, HF141-50, 30 cm QAXIAL S02S02-23-00300
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	HF141-50
Length:	30 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	18 GHz
Impedance:	50 Ohm

Go to product page CID-207

Cable assembly, 2x SMA male/right angle male, ...

Order code:	CID-214
	Cable assembly, 2x SMA male/right angle male, SM141, 30 cm QAXIAL S02S07-23-00300
RoHS compliant:	Yes
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > right angle male
Cable type:	SM141
Length:	30 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	12.4 GHz
Impedance:	50 Ohm

Go to product page CID-214

Cable assembly, 2x SMA male/right angle male, ...

Order code:	CID-218
	Cable assembly, 2x SMA male/right angle male, UT141-AL, 1.3 m
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > right angle male
Cable type:	UT141-AL
Length:	1.3 m
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	12.4 GHz
Impedance:	50 Ohm

Go to product page CID-218

Cable assembly, 2x SMA male, UT141-AL, 90 cm

Order code:	CID-219
	Cable assembly, 2x SMA male, UT141-AL, 90 cm
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	UT141-AL
Length:	90 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	18 GHz
Impedance:	50 Ohm

Go to product page CID-219

Cable assembly, 2x SMA male, UT141-AL, 1.25 m

Order code:	CID-220
	Cable assembly, 2x SMA male, UT141-AL, 1.25 m
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > male
Cable type:	UT141-AL
Length:	1.25 m
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	18 GHz
Impedance:	50 Ohm

Go to product page CID-220

Cable assembly, 2x SMA right angle male, SM141, 25.5 ...

Order code:	CID-223
	Cable assembly, 2x SMA right angle male, SM141, 25.5 cm
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	right angle male > right angle male
Cable type:	SM141
Length:	25.5 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	24 GHz
Impedance:	50 Ohm

Go to product page CID-223

Cable assembly, SMA male, UT141-AL, 10 cm

Order code:	CID-224
	Cable assembly, SMA male, UT141-AL, 10 cm
Application:	high temperature / high power, microwave
Connectors:	SMA > not connected
Type:	male
Cable type:	UT141-AL
Length:	10 cm
Flexibility:	handyform
Dielectric:	PTFE
Impedance:	50 Ohm

Go to product page CID-224

Cable assembly, SMA male, UT141-AL, 40 cm

Order code:	CID-225
	Cable assembly, SMA male, UT141-AL, 40 cm
Application:	high temperature / high power, microwave
Connectors:	SMA > not connected
Type:	male
Cable type:	UT141-AL
Length:	40 cm
Flexibility:	handyform
Dielectric:	PTFE
Impedance:	50 Ohm

Go to product page CID-225

Cable assembly, 2x SMA male/right angle male, ...

Order code:	CID-226
	Cable assembly, 2x SMA male/right angle male, UT141-AL, 35 cm
Application:	high temperature / high power, microwave
Connectors:	SMA > SMA
Type:	male > right angle male
Cable type:	UT141-AL
Length:	35 cm
Flexibility:	handyform
Dielectric:	PTFE
Maximum frequency:	8 GHz
Impedance:	50 Ohm

Go to product page CID-226
