RF and microwave SMD MLC capacitors

HiQ SMD MLC capacitor, P90, 0.1pF, ±0.1pF, 250V, 0505

Order code:	100A-0P1-B250
	HiQ SMD MLC capacitor, P90, 0.1pF, ±0.1pF, 250V, 0505 ATC / Kyocera AVX 100A0R1BT250XT
Conditions:	N (The product is brand new)
Series:	100A
Capacitance:	0.1 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	250 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page 100A-0P1-B250

HiQ SMD MLC capacitor, P90, 0.1pF, ±0.1pF, 1500V

Order code:	100B-0P1-B1500
	HiQ SMD MLC capacitor, P90, 0.1pF, ±0.1pF, 1500V ATC / Kyocera AVX 100B0R1BT1500XT
Conditions:	N (The product is brand new)
Series:	100B
Capacitance:	0.1 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	1500 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	B (1111)

Go to product page 100B-0P1-B1500

HiQ SMD MLC capacitor, P100, 0.1pF, ±0.1pF, 50V, 0505

Order code:	CHA-0P1-B50
	HiQ SMD MLC capacitor, P100, 0.1pF, ±0.1pF, 50V, 0505 Temex 500CHA0R1BGLE
Conditions:	N- (The product is brand new but it comes from an old production)
Series:	CHA
Capacitance:	0.1 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	50 V
Tcc (ppm/ºC):	100 ±30 (P100)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page CHA-0P1-B50

HiQ SMD MLC capacitor, P90, 0.2pF, ±0.1pF, 250V, 0505

Order code:	100A-0P2-B250
	HiQ SMD MLC capacitor, P90, 0.2pF, ±0.1pF, 250V, 0505 ATC / Kyocera AVX 100A0R2BT250XT
Conditions:	N (The product is brand new)
Series:	100A
Capacitance:	0.2 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	250 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page 100A-0P2-B250

HiQ SMD MLC capacitor, P90, 0.2pF, ±0.1pF, 1500V

Order code:	100B-0P2-B1500
	HiQ SMD MLC capacitor, P90, 0.2pF, ±0.1pF, 1500V ATC / Kyocera AVX 100B0R2BT1500XT
Conditions:	N (The product is brand new)
Series:	100B
Capacitance:	0.2 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	1500 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	B (1111)

Go to product page 100B-0P2-B1500

HiQ SMD MLC capacitor, P100, 0.2pF, ±0.1pF, 50V, 0505

Order code:	CHA-0P2-B50
	HiQ SMD MLC capacitor, P100, 0.2pF, ±0.1pF, 50V, 0505 Temex 500CHA0R2BGLE
Conditions:	N- (The product is brand new but it comes from an old production)
Series:	CHA
Capacitance:	0.2 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	50 V
Tcc (ppm/ºC):	100 ±30 (P100)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page CHA-0P2-B50

HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 150V, 0505

Order code:	100A-0P3-B150
	HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 150V, 0505 ATC / Kyocera AVX 100A0R3BT150XT
Conditions:	N (The product is brand new)
Series:	100A
Capacitance:	0.3 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	150 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page 100A-0P3-B150

HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 250V, 0505

Order code:	100A-0P3-B250
	HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 250V, 0505 ATC / Kyocera AVX 100A0R3BT250XT
Conditions:	N (The product is brand new)
Series:	100A
Capacitance:	0.3 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	250 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page 100A-0P3-B250

HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 1500V

Order code:	100B-0P3-B1500
	HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 1500V ATC / Kyocera AVX 100B0R3BT1500XT
Conditions:	N (The product is brand new)
Series:	100B
Capacitance:	0.3 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	1500 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	B (1111)

Go to product page 100B-0P3-B1500

HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 500V

Order code:	100B-0P3-B500
	HiQ SMD MLC capacitor, P90, 0.3pF, ±0.1pF, 500V ATC / Kyocera AVX 100B0R3BT500XT
Conditions:	N (The product is brand new)
Series:	100B
Capacitance:	0.3 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	500 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	B (1111)

Go to product page 100B-0P3-B500

SMD MLC capacitor, NP0, 0.3pF, 500V, ±0.1pF

Order code:	800B-0P3-B500
	SMD MLC capacitor, NP0, 0.3pF, 500V, ±0.1pF ATC / Kyocera AVX 800B0R3BT500XT
Conditions:	N (The product is brand new)
Series:	800B
Capacitance:	0.3 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	500 V
Tcc (ppm/ºC):	0 ±30 (NP0)
Dielectric material:	ceramic
Package type :	B (1111)

Go to product page 800B-0P3-B500

HiQ SMD MLC capacitor, P100, 0.3pF, ±0.1pF, 200V, 0505

Order code:	CHA-0P3-B200
	HiQ SMD MLC capacitor, P100, 0.3pF, ±0.1pF, 200V, 0505 Temex 201CHA0R3BSLE
Conditions:	N- (The product is brand new but it comes from an old production)
Series:	CHA
Capacitance:	0.3 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	200 V
Tcc (ppm/ºC):	100 ±30 (P100)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page CHA-0P3-B200

HiQ SMD MLC capacitor, P90, 0.4pF, ±0.1pF, 250V, 0505

Order code:	100A-0P4-B250
	HiQ SMD MLC capacitor, P90, 0.4pF, ±0.1pF, 250V, 0505 ATC / Kyocera AVX 100A0R4BT250XT
Conditions:	N (The product is brand new)
Series:	100A
Capacitance:	0.4 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	250 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page 100A-0P4-B250

HiQ SMD MLC capacitor, P90, 0.4pF, ±0.1pF, 1500V

Order code:	100B-0P4-B1500
	HiQ SMD MLC capacitor, P90, 0.4pF, ±0.1pF, 1500V ATC / Kyocera AVX 100B0R4BT1500XT
Conditions:	N (The product is brand new)
Series:	100B
Capacitance:	0.4 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	1500 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	B (1111)

Go to product page 100B-0P4-B1500

HiQ SMD MLC capacitor, P100, 0.4pF, ±0.1pF, 200V, 0505

Order code:	CHA-0P4-B200
	HiQ SMD MLC capacitor, P100, 0.4pF, ±0.1pF, 200V, 0505 Temex 201CHA0R4BSLE
Conditions:	N- (The product is brand new but it comes from an old production)
Series:	CHA
Capacitance:	0.4 pF
Tolerance (code):	B
Tolerance (value) (±):	0.1 pF
Max. working voltage:	200 V
Tcc (ppm/ºC):	100 ±30 (P100)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page CHA-0P4-B200
