Leaded ceramic capacitors

High voltage leaded ceramic capacitor, 560 pF, 2kV

Order code:	CRA-560P
	High voltage leaded ceramic capacitor, 560 pF, 2kV muRata DE0907R561K2K
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc, high voltage
Capacitance :	560 pF
Tolerance (±):	10%
Working voltage (DC):	2 kV
Dielectric type:	R (+15% / -30%)
Size or diameter:	Ø9 mm
Pitch:	7.5 mm

Go to product page CRA-560P

Leaded ceramic capacitor, 560 pF, 50V

Order code:	CRN-560P
	Leaded ceramic capacitor, 560 pF, 50V muRata RPE110Z5U561M050
Conditions:	N (The product is brand new)
Capacitor type:	ceramic multilayer
Capacitance :	560 pF
Tolerance (±):	20%
Working voltage (DC):	50 V
Dielectric type:	Z5U (+22% / -56%)
Size or diameter:	3.5 x 3.1 mm
Pitch:	2.5 mm

Go to product page CRN-560P

Leaded HF and VHF ceramic capacitor, 680 pF, 500V

Order code:	CPHK-680P
	Leaded HF and VHF ceramic capacitor, 680 pF, 500V Microelectronics Ltd. SHQ34-681F
Conditions:	N (The product is brand new)
Capacitor type:	porcelain multilayer, RF medium power
Capacitance :	680 pF
Tolerance (±):	1%
Working voltage (DC):	500 V
Size or diameter:	14 x 14 mm
Pitch:	7.5 mm

Go to product page CPHK-680P

Leaded ceramic capacitor, 680 pF, 50V

Order code:	CRN-680P
	Leaded ceramic capacitor, 680 pF, 50V Hitano R15W681K1HL2L
Conditions:	N (The product is brand new)
Capacitor type:	ceramic multilayer
Capacitance :	680 pF
Tolerance (±):	10%
Working voltage (DC):	50 V
Dielectric type:	X7R (±15%)
Size or diameter:	3.8 x 3.8 mm
Pitch:	2.54 mm

Go to product page CRN-680P

Leaded ceramic capacitor, 820 pF, 50V

Order code:	CRN-820P-A
	Leaded ceramic capacitor, 820 pF, 50V
Conditions:	N (The product is brand new)
Capacitor type:	ceramic multilayer
Capacitance :	820 pF
Working voltage (DC):	50 V
Size or diameter:	4 x 3.5 mm
Pitch:	2.5 mm

Go to product page CRN-820P-A

Leaded ceramic capacitor, 820 pF, 50V

Order code:	CRN-820P-B
	Leaded ceramic capacitor, 820 pF, 50V Taiyo Yuden RO U05 B821K-L05AC
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc
Capacitance :	820 pF
Tolerance (±):	10%
Working voltage (DC):	50 V
Dielectric type:	X7R (±15%)
Size or diameter:	Ø5 mm
Pitch:	2.5 mm

Go to product page CRN-820P-B

Leaded HF and VHF ceramic capacitor, 1.3 nF, 500V

Order code:	CPHK-1N3
	Leaded HF and VHF ceramic capacitor, 1.3 nF, 500V Microelectronics Ltd. SHQ34-132F
Conditions:	N (The product is brand new)
Capacitor type:	porcelain multilayer, RF medium power
Capacitance :	1.3 nF
Tolerance (±):	1%
Working voltage (DC):	500 V
Size or diameter:	14 x 14 mm
Pitch:	7.5 mm

Go to product page CPHK-1N3

Leaded high voltage ceramic capacitor, 1 nF, 1kV

Order code:	CRA-1N-1
	Leaded high voltage ceramic capacitor, 1 nF, 1kV muRata DEHR33A102KN2A
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc, high voltage
Capacitance :	1 nF
Tolerance (±):	10%
Working voltage (DC):	1 kV
Size or diameter:	Ø9 mm
Pitch:	5 mm

Go to product page CRA-1N-1

Leaded high voltage ceramic capacitor, 1 nF, 2kV

Order code:	CRA-1N-2
	Leaded high voltage ceramic capacitor, 1 nF, 2kV muRata DE0805-B102K2K
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc, high voltage
Capacitance :	1 nF
Tolerance (±):	10%
Working voltage (DC):	2 kV
Dielectric type:	Y5P (±10%)
Size or diameter:	Ø8 mm
Pitch:	5 mm

Go to product page CRA-1N-2

Leaded high voltage ceramic capacitor, 1.5 nF, 3.15kV

Order code:	CRA-1N5
	Leaded high voltage ceramic capacitor, 1.5 nF, 3.15kV muRata DE1507-477R152K3K-LF
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc, high voltage
Capacitance :	1.5 nF
Tolerance (±):	10%
Working voltage (DC):	3.15 kV
Dielectric type:	R (+15% / -30%)
Size or diameter:	Ø15 mm
Pitch:	7.5 mm

Go to product page CRA-1N5

Leaded ceramic capacitor, 1 nF, 50V

Order code:	CRN-1N
	Leaded ceramic capacitor, 1 nF, 50V Taiyo Yuden ROU04F102Z-L45AC
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc
Capacitance :	1 nF
Tolerance (±):	+80% / -20%
Working voltage (DC):	50 V
Dielectric type:	F (+30% / -80%)
Size or diameter:	Ø4 mm
Pitch:	2.5 mm

Go to product page CRN-1N

Leaded ceramic capacitor, 1.2 nF, 200V

Order code:	CRN-1N2
	Leaded ceramic capacitor, 1.2 nF, 200V
Conditions:	N (The product is brand new)
Capacitor type:	ceramic multilayer
Capacitance :	1.2 nF
Tolerance (±):	10%
Working voltage (DC):	200 V
Size or diameter:	3.5 x 3 mm
Pitch:	5 mm

Go to product page CRN-1N2

Leaded ceramic capacitor, 1.5 nF, 50V

Order code:	CRN-1N5
	Leaded ceramic capacitor, 1.5 nF, 50V
Conditions:	N (The product is brand new)
Capacitor type:	ceramic multilayer
Capacitance :	1.5 nF
Tolerance (±):	5%
Working voltage (DC):	50 V
Dielectric type:	C0G (0 ±30 ppm/°C)
Size or diameter:	5 x 5 mm
Pitch:	5 mm

Go to product page CRN-1N5

Leaded high voltage ceramic capacitor, 2.2 nF, 6.3kV

Order code:	CRA-2N2-6
	Leaded high voltage ceramic capacitor, 2.2 nF, 6.3kV
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc, high voltage, RF power
Capacitance :	2.2 nF
Tolerance (±):	20%
Working voltage (DC):	6.3 kV
Dielectric type:	X7R (±15%)
Size or diameter:	Ø34 mm
Pitch:	20 mm

Go to product page CRA-2N2-6

Leaded high voltage ceramic capacitor, 2.2 nF, 2kV

Order code:	CRA-2N2A
	Leaded high voltage ceramic capacitor, 2.2 nF, 2kV Vishay Roederstein RBX222SBBSQRK
Conditions:	N (The product is brand new)
Capacitor type:	ceramic disc, high voltage
Capacitance :	2.2 nF
Tolerance (±):	+50% / -20%
Working voltage (DC):	2 kV
Size or diameter:	Ø10 mm
Pitch:	5 mm

Go to product page CRA-2N2A
