2.92mm female to SMP plug (male) coaxial adapter, dc - 40 GHz precision series

Order code:	ADA-134
	2.92mm female to SMP plug (male) coaxial adapter, dc - 40 GHz precision series QAXIAL 2.92M-SMP42-01PS
Conditions:	N (The product is brand new)
Adapter Series:	2.92mm > SMP
Adapter Type:	female > male
Impedance :	50 Ohm
Maximum frequency:	40 GHz
Geometry:	straight
Mounting:	free hanging
Insulator:	PEI
Body material:	stainless steel
Body finishing:	passivated

Go to product page ADA-134

Clamp 7/16 male OMNI FIT™ coaxial connector for CELLFLEX® 7/8'' cables, IP68

Order code:	C716-11
	Clamp 7/16 male OMNI FIT™ coaxial connector for CELLFLEX® 7/8'' cables, IP68 RFS 716M-LCF78-C03
Conditions:	N (The product is brand new)
Connector series:	7/16 DIN
Gender:	male
Impedance:	50 Ohm
Maximum frequency:	6 GHz
Geometry:	straight
Mounting:	free hanging
Termination style:	cable - clamp
Coupling:	threaded
Cable type:	CELLFLEX® LCF78-50J, HELIAX® LDF5-50A, SUCOFEED_7/8
Insulator:	PTFE
IP rating:	IP68
Body finishing:	trimetal/silver

Go to product page C716-11

Electromechanical coaxial relay, failsafe, SPDT, 12V, 18GHz

Order code:	SW-SMA-01
	Electromechanical coaxial relay, failsafe, SPDT, 12V, 18GHz Radiall R570412000
Conditions:	N (The product is brand new)
Application:	RF and high frequency
Configuration:	coaxial
Contact type:	SPDT
Max. switching current:	250 mA
Coil voltage :	12 V
Max. power handling:	240 W
Max. frequency:	18 GHz
Impedance:	50 Ohm
Connector type:	SMA female
Latching switch:	No

Go to product page SW-SMA-01

Coaxial termination, 2.4mm male, 50Ω, 1W, 50GHz

Order code:	TC-24-01
	Coaxial termination, 2.4mm male, 50Ω, 1W, 50GHz QAXIAL DLY-5001-50
Conditions:	N (The product is brand new)
Impedance:	50 Ohm
Maximum frequency:	50 GHz
Connector:	2.4mm
Gender:	male
Power:	1 W
Body material:	stainless steel
Body finishing:	passivated
Insulator:	PEI

Go to product page TC-24-01

HiQ SMD MLC capacitor, P90, 2.4pF, ±0.25pF, 150V, 0505

Order code:	100A-2P4-C150
	HiQ SMD MLC capacitor, P90, 2.4pF, ±0.25pF, 150V, 0505 American Technical Ceramics 100A2R4CT150XT
Conditions:	N- (The product is brand new but it comes from an old production)
Series:	100A
Capacitance:	2.4 pF
Tolerance (code):	C
Tolerance (value) (±):	0.25 pF
Max. working voltage:	150 V
Tcc (ppm/ºC):	90 ±20 (P90)
Dielectric material:	porcelain
Package type :	A (0505)

Go to product page 100A-2P4-C150

HiQ SMD MLC capacitor, NP0, 2200pF, ±20%, 50V, 1111

Order code:	700B-2N2-M50
	HiQ SMD MLC capacitor, NP0, 2200pF, ±20%, 50V, 1111 American Technical Ceramics 700B222MT50XT
Conditions:	N- (The product is brand new but it comes from an old production)
Series:	700B
Capacitance:	2.2 nF
Tolerance (code):	M
Tolerance (value) (±):	20%
Max. working voltage:	50 V
Tcc (ppm/ºC):	0 ±30 (NP0)
Dielectric material:	ceramic
Package type :	B (1111)

Go to product page 700B-2N2-M50

Bulkhead solder N female coaxial connector for RG402/.141 **END SERIES**

Order code:	N-53
	Bulkhead solder N female coaxial connector for RG402/.141 **END SERIES** QAXIAL N15-10-01
Conditions:	N (The product is brand new)
Connector series:	N
Gender:	female
Impedance:	50 Ohm
Maximum frequency:	6 GHz
Geometry:	straight
Mounting:	bulkhead - rear
Termination style:	cable - crimp
Coupling:	threaded
Cable type:	.141 handy-form, .141 semi-rigid, HF141-50, HF141-50-FEP, MULTIFLEX_141, RG402, SS402, SUCOFORM_141, SUCOFORM_141_FEP
Insulator:	PTFE
Body material:	brass
Body finishing:	nickel

Go to product page N-53

RF mixer, 5 - 1200 MHz, 17 dBm, plug-in

Order code:	SRA-173H
	RF mixer, 5 - 1200 MHz, 17 dBm, plug-in Mini-Circuits SRA-173H
Conditions:	N- (The product is brand new but it comes from an old production)
RF frequency:	5 - 1200 MHz
LO frequency:	5 - 1200 MHz
IF frequency:	dc - 1200 MHz
LO power level:	17 dBm
Max. conversion loss:	8.5 dB
Operating temperature (°C):	-55 / +100
Mounting style:	plug-in
Mixer type:	triple-balanced

Go to product page SRA-173H

4-hole flange field replaceable 2.92mm male coaxial connector, for 0.38mm pin

Order code:	2.92MM-04
	4-hole flange field replaceable 2.92mm male coaxial connector, for 0.38mm pin QAXIAL 2.92M14-4H-01
Conditions:	N (The product is brand new)
Connector series:	2.92mm (K)
Gender:	male
Impedance:	50 Ohm
Maximum frequency:	40 GHz
Geometry:	straight
Mounting:	4-hole flange
Termination style:	female contact
Coupling:	threaded
Insulator:	PEI
Body material:	stainless steel
Body finishing:	passivated

Go to product page 2.92MM-04

N female to N female coaxial adapter, low PIM, IP68

Order code:	ADA-140
	N female to N female coaxial adapter, low PIM, IP68 RFS NF-NF
Conditions:	N (The product is brand new)
Adapter Series:	N > N
Adapter Type:	female > female
Impedance :	50 Ohm
Maximum frequency:	6 GHz
Geometry:	straight
Mounting:	free hanging
Insulator:	PTFE
Body material:	brass
Body finishing:	ternary alloy
IP rating:	IP68

Go to product page ADA-140

SMA coaxial attenuator, 30 dB, 2 W, 18 GHz

Order code:	ATFS-18G-30Q
	SMA coaxial attenuator, 30 dB, 2 W, 18 GHz QAXIAL ATS-3002-18
Conditions:	N (The product is brand new)
Connector type:	SMA
Gender:	male / female
Impedance:	50 Ohm
Attenuation:	30 dB
Maximum frequency:	18 GHz
Power :	2 W
Body material:	stainless steel
Body finishing:	passivated

Go to product page ATFS-18G-30Q

Crimp reverse polarity SMA (RP-SMA) male coaxial connector for LMR-240 / LLF240 / SPUMA_240

Order code:	SMAR-07
	Crimp reverse polarity SMA (RP-SMA) male coaxial connector for LMR-240 / LLF240 / SPUMA_240 Huber+Suhner 11_SMA-R50-4-97/133_NH
Conditions:	N (The product is brand new)
Connector series:	RP-SMA
Gender:	male
Impedance:	50 Ohm
Maximum frequency:	18 GHz
Geometry:	straight
Mounting:	free hanging
Termination style:	cable - crimp
Coupling:	threaded
Cable type:	LLF240, LMR240, SPUMA_240, S_04262_B-01, S_04272_B
Insulator:	PTFE
Body material:	brass
Body finishing:	SUCOPLATE®

Go to product page SMAR-07
