10.6935 MHz crystal band-pass filter, 8 poles, for SSB

Name: 10.6935 MHz crystal band-pass filter, 8 poles, for SSB
Brand: TEW
SKU: F-10M6935
Price: 23.86 EUR
Availability: InStock

Product conditions: N-

$32.59

/ pc

(VAT tax not included)

Availability
Stock (immediate dispatch)	23 pcs

Volume discounts
Q.ty	Unit Price	Ext. price
1+	$32.59	$32.59
5+	$29.68	$148.39
10+	$27.25	$272.46
25+	$25.90	$647.50
(VAT tax not included)

Compliance
Country of origin	JP
EU Tariff Code	85416000
Weight	14.00 g
RoHS	No
REACH	Not available

Center freq. min. (or fixed):
10.6935 MHz
Bandwidth:
2 kHz
Insertion loss (max.):
3 dB
Selectivity (min.) :
60 dB
Input/output impedance :
600 Ω
Product type:
PCB mount
Mounting:
thru-hole
Package:
36 x 10 mm - h 22 mm

10.6935 MHz crystal band-pass filter, 8 poles, for SSB

SPECIFICATIONS:
- Bandwidth (-3dB): 2 KHz
- Bandwidth (-6dB): 2.3 KHz
- Selectivity: >60 dB
- Impedance: 600 Ω // 15pF
- Shape factor (6/60dB): 1.9
- Insertion loss: 3 dB (typical)
- Dimensions: 36 x 10 mm, h 22 mm

Order code: F-10M6935

Category: RF band-pass filters

No document found
